EAC-601 : Combination Louver/Damper, Drainable Blade, 6-inch Depth
EAC-601 : Combination Louver/Damper, Drainable Blade, 6-inch Depth
Model EAC-601 is an extruded aluminum combination louver-damper designed with drainable-style blades and concealed linkage housed within the jambs for protected operation and a clean architectural appearance. It functions as a conventional louver when open and provides tight shutoff against air and weather when closed. Typically furnished with factory-mounted and factory-adjusted electric actuators, it offers reliable airflow control and simplified installation.
Product Highlights
| Blade Orientation |
Horizontal
|
|---|---|
| Blade Type |
Drainable
|
| Operable Type |
Combination
|
| Frame Depth (Inches) |
6
|
| Certifications |
AMCA 500-L Water Penetration and Air Performance
|
| Free Area for 4' x 4' (%) |
46
|
| Free Area for 4' x 4' (ft square) |
7.41
|
| Material |
Aluminum
|
| Minimum Size |
12 in. W x 16 in. H
|
| Maximum Single Section Size |
60 in. W x 96 in. H
|
| Beginning Point of Water Penetration (ft/min) |
1,024
|
